Anchor

Every map starts with an anchor—the user or stakeholder need. This sets the context for all dependencies and components below.

anchor Business [0.95, 0.63]
tip

Start every map by identifying the anchor and their needs. This sets the context for all dependencies and components below.

A Wardley Map always starts with an anchor—the user or stakeholder need. The anchor represents the situation you want to influence, often called the "battle at hand." It is the top-most element in the value chain and all other components ultimately serve this need.

In a competitive business landscape map, instead of magnetic North, the anchor is the User being served and their corresponding needs. This context-specific focus ensures the map reflects the right perspective and strategic priorities.

Syntax​

anchor Name [Visibility (Y Axis), Maturity (X Axis)]
  • Name: The user, stakeholder, or need.
  • Visibility (Y Axis): How visible the anchor is (usually 1.0 for the user).
  • Maturity (X Axis): The stage of evolution (often 0 for the anchor).

Example​

anchor Customer [0.95, 0.63]
anchor Business [0.95, 0.53]

Visual Example​

Anchor Example
